Chemours Teflon™ Coating Services

Services

Ensuring optimal performance of Teflon coating requires the proper application process to be followed. Chemours created the Licensed Industrial Applicators (LIA) program that includes approximately 30 coaters nationwide. In order to be selected as an LIA, companies must meet a list of criteria as well as quality of workmanship. Crest Coating is proud to be a member of the elite group of Chemours Licensed Industrial Applicators for more than 50 years. This is a source of pride for us, and a source of confidence for our customers.

Chemours Teflon Coatings

Teflon Coating Spray or Dip Process

The variety of Chemours Teflon industrial spray coatings is extensive, and for any particular use, there may be several Chemours Teflon™ coatings that will perform well, using either a spray or dip process. Drawing on the experience of a Licensed Industrial Applicator ensures the best Chemours Teflon spray coating or dip coating for a given application, whether it be PTFE®FEP®PFA®, ETFE®, Chemours Teflon-S™, or others.

Crest’s engineering and expertise in Teflon coating services is recognized nationwide. We can help engineer the best system for your requirements. Customers from all parts of America routinely send components to us for PTFE coating services.

Call us today at 1-888-709-2760

Thermal

To view thermal properties, download the attached PDF. Download PDF

Electrical

To view electrical properties, download the attached PDF. Download PDF

Mechanical

To view mechanical properties, download the attached PDF. Download PDF

Benefits

Nonstick – Very few solid substances will permanently adhere to a Chemours Teflon™ coated finish. Although tacky materials may show some adhesion, almost all substances release easily.

Low Coefficient of Friction – The coefficient of friction of Chemours Teflon™ is generally in the range of 0.05 to 0.20, depending on the load, sliding speed, and particular Chemours Teflon coating used.

Nonwetting – Since surfaces coated with Chemours Teflon™ spray are both oleophobic and hydrophobic, they are not readily wetted. Cleanup is easier and more thorough – in many cases, surfaces are self-cleaning.

Heat Resistance – Chemours Teflon™ industrial coatings can operate continuously at temperatures up to 287°C/550°F and can be used for intermittent service up to 316°C/600°F with adequate ventilation.

Unique Electrical Properties – Chemours Teflon™ coating spray has high dielectric strength, low dissipation factor, and very high surface resistivity. By special techniques, it can even be made electroconductive enough to be used as an anti-static coating.

Cryogenic Stability – Many Chemours Teflon™ industrial coatings withstand severe temperature extremes without loss of physical properties. Chemours Teflon coatings may be used at temperatures as low as -270°C/-454°F.

Chemical Resistance – Chemours Teflon™ is normally unaffected by chemical environments. The only chemicals known to affect all Chemours Teflon™ industrial coatings are molten alkali metals and highly reactive fluorinating agents.

Surfaces

  • Aluminum
  • Brass
  • Carbon Steel
  • Fiberglass
  • Glass
  • Magnesium
  • Plastics
  • Rubber
  • Stainless Steel
  • Steel Alloys

Friction

Coefficient of Friction – 0.05 to 0.20

Temp

Use Temperature Range -270°C to 316°C
-454°F to 600°F

Pre-Treatment

The Pre-Treatment process – Optimum adhesion is obtained by roughening the surface before applying the coating spray. Except where specifically mentioned, most Chemours Teflon™ industrial coatings require a media blast and primer coat.

Equipment List

View In-House Capabilities

Types of Chemours Teflon™ Coatings

Chemours Teflon PTFE Coating Services

Polytetrafluoroethylene (PTFE) nonstick coatings are two-coat or three-coat (primer/topcoat) systems. These products have the highest operating temperature of any fluoropolymer (287°C/550°F), an extremely low coefficient of friction, good abrasion resistance, and good chemical resistance. PTFE coating services are available only in water-based liquid form.

Chemours Teflon FEP

Fluorinated Ethylene Propylene Copolymer nonstick coatings melt and flow during baking to provide nonporous films. These coatings provide excellent chemical resistance. In addition to low friction, FEP coatings have excellent nonstick properties. Maximum use temperature is 204°C/400°F. FEP is available in water-based liquid and powder forms.

Chemours Teflon PFA

PFA (perfluoroalkoxy) nonstick coatings melt and flow during baking to provide nonporous films. PFA offers the additional benefits of higher continuous use temperature (260°C/500°F), film thicknesses up to 1,000 micrometers (40 mils), and greater toughness than PTFE coating or FEP. This combination of properties makes PFA an excellent choice for a wide variety of uses, especially those involving chemical resistance. PFA is available in both water-based liquid and powder forms.

Chemours Teflon ETFE

ETFE is a copolymer of ethylene and tetrafluoroethylene and is also sold under the Tefzel® trademark. Although not fully fluorinated, ETFE has excellent chemical resistance and can operate continuously at 149°C/300°F. This resin is the toughest of the fluoropolymers and can be applied at film builds up to 1,000 micrometers (40 mils) to provide a highly durable finish. ETFE is available in powder form.

Chemours Teflon-S One Coat

These solvent-based liquid coatings are formulated with special blends of fluoropolymers and other high-performance resins to improve toughness and abrasion resistance. Because the film components stratify during baking, most of the fluoropolymer properties (such as low friction and nonstick character) are retained. The resins provide adhesion and abrasion resistance. Depending on the application, these materials may require sand blasting, etching or surface oxidation to obtain the desired results. Bake requirements vary, depending on the specific coating, from 163°C/325°F to 316°C/600°F.

Chemours Teflon-S Dry Lubricant

Dry lubricant coatings are special versions of Chemours Teflon™-S technology designed to provide lubrication under high-pressure/velocity (PV) conditions. These products are solvent-based, one-coat systems that are usually cured between 148°C/300°F and 371°C/700°F.

Certifications

Teflon

Teflon Industrial Coatings Licensed Industrial Applicator
Chemours

FAQ About Teflon Coating Spray

How is Teflon coating applied?
Best adhesion is obtained by first roughening the surface to be coated. Most Teflon coatings are applied with a spray machine that uses compressed air, much like spray paint. Sometimes a dip process is used to apply the Teflon coating. The objects are then baked until the Teflon forms a solid coat. What is Teflon coating commonly used for?
Due to its nonstick, chemical resistance, corrosion protection, dielectric strength, and heat resistant capabilities, Teflon coating spray can be used on a wide variety of surfaces. Offering a permanent lubricant solution. Applications include everything from cookware, auto parts, semi-conductor equipment, and aerospace assemblies to computer components, and nuts and bolts used in extreme environments. How long does Teflon spray take to dry?
Most coating spray will dry to the touch very quickly in a few minutes, but in order to utilize the functional characteristics the coatings require baking temperatures depending on the specific coating, from 163°C/325°F to 400°C/750°F. Is Teflon coating waterproof?
Yes, the Teflon coating spray is resistant to liquid and is therefore waterproof. Is Teflon coating durable?
Due to high abrasion resistance, Teflon coatings have excellent durability and toughness.
