Whitford Xylan® Coating Products

Print FriendlyPrint Friendly
xylan coating

Quality Approved Coater SEAL

Whitford recognizes the importance of a properly engineered and applied coating system. A “Quality Approved Coater” program was established to provide industry competent sources to apply their products. Crest Coating is a charter member in this distinguished network of Xylan coating experts.

Whitford Xylan® coatings have a broad range of properties which make them ideal for a variety of applications. Whitford Xylan® coatings differ from traditional fluoropolymer coatings in one very important aspect … they are composite materials. Lubricants with the lowest-known coefficient of friction are combined with the newest high temperature resistant organic polymers to create Whitford Xylan® coatings.

Specifications

Outstanding Properties of Whitford Xylan®

 spacer
  • Low coefficient of friction – as low as 0.02
  • Excellent wear resistance – even under extreme pressures
  • Corrosion and weather protection against sunlight, saltwater, and harsh chemicals
  • Xylan coating offers a wide operating temperature range – -420F to +550F
  • Wide array of colors to help color code your products
  • Xylan coating has excellent adhesion to a variety of substrates including most metals, plastics, ceramics and wood
  • Pliability allowing Xylan® to bend freely and repeatedly without breaking
  • Flexible curing schedule from ambient to 750F
spacer

Applicable Surfaces

 spacer Aluminum
Brass
Carbon Steel
Fiberglass
Glass
Magnesium
Plastics
Rubber
Stainless Steel
Steel Alloys
Wood
spacer

Coefficient of Friction



 spacer 0.02 to 0.20

Use Temperature Range

 spacer -420ºF to 550ºF (-250ºC to 285ºC)
spacer

Pre-Treatment Process

 spacer Optimum adhesion is obtained by roughening the surface before applying the coating. Except where specifically mentioned, most Xylan® industrial coatings require a sandblast and primer coat.
spacer

Equipment List

 spacer See In-House Capabilities

Types of Whitford Xylan® Coatings

1000 Series

 spacer Premium dry-film lubricant, with widely varying properties; hard, heat stable, excellent broadband corrosion barrier; flexible cure schedule; can be formulated to have good release; electrical conductivity; fair UV stability. Applied by spraying. Typical applications include; sliding mechanisms, bearings, large fasteners, power screws, valves, machine parts, pistons.
spacer

1400 Series

 spacer Excellent chemical resistance, particularly to bases. Good UV stability. Applied by spraying. Typical applications include; large fasteners, automotive components.
spacer

1500 Series

 spacer Xylan 1500 coatings are decorative enamels with low-friction properties and stain resistance which can operate at elevated temperatures. Unlike many fluoropolymer finishes, coatings in this series may be produced in virtually any color.
spacer

8000 Series

 spacer Similar characteristics as the 1000 Series but utilizes materials approved by the FDA for food use. Typical applications include; warming plates, faucet valves, heating elements, ice makers, pans,toasters.
spacer

PFA Plus

 spacer Excellent chemical and temperature resistance as well as low friction properties. Applied by spraying. Typical applications include: plastic and urethane molds, bakery products, chemical storage tanks.
